• .100"(2.54mm) Wire-to-Board Crimp Terminal Housings
    • Current rating: 3A AC, DC.(AWG#22)
    • Voltage Rating: 250V AC,DC
    • Withstanding Voltage: 800V AC/minute.
    • Insulation resistance: 1000MΩ min
    • Contact resistance: Initial Value/ 20mΩ max
    • Temperature rise: -25'C ~ 85'C.

    123

  • test20221205 test20221205



    Inquiry Info.

  • 1.asn-Srh-asun_css 2.54 mm Crimp Terminal

    Material: Brass
    Wire Range: #22~ #28 AWG
    Use in 02 ~ 20P  : -1  /Used in 21 ~ 40 : -2
    Finished: Tin-plated /Gold-flash in contact area
    Packaging:  T1: 10kpcs/Reel

    Inquiry Info. 25402T

  • 25402H-X-X-X 2.54 mm Crimp Terminal Housing



               Circuit: 1, 2 , 3, 4 ~  40

               Material: Nylon 66 UL 94V0

               Color: Black

               Packaging: 1Kpcs/bag

    Inquiry Info. 25402H

  • 25407TF-X-X-X 2.54 mm Crimp Terminal



            Material: Brass /Phosphor bronze

            Wire Range: #22~ #24 AWG

            Finished: Tin-plated /Gold-flash in contact area

            Packaging:  10kpcs/Reel

    Inquiry Info. 25407TF

  • 25407HM-X-X-X-X 2.54 mm Crimp Terminal Housings



               Lock : A-Non-polarized /B-Polarized /C-Latch

               Circuit: 2, 3 , 4 ~  16

               Material: Nylon 66,  UL 94V0

               Color: Black

               Packaging: 1Kpcs/bag

    Inquiry Info. 25407HM 25407HM 25407HM

  • 25407WS-X-X-X 2.54 mm Straight Angel Header



               Circuit: 2, 3, 4~ 12

               Material:  PBT + glass fiber   UL 94V0

               Contact:  Tin-plated Brass , Gold-plated Brass

               Color:  Black

               Packaging: 1kpcs/Bag

    Inquiry Info. 25407WS

  • 25407WR-X-X-X 2.54 mm Right Angel Header



               Circuit: 2, 3, 4~ 12

               Material:  PBT + glass fiber   UL 94V0

               Contact:  Tin-plated Brass , Gold-plated Brass

               Color:  Black

               Packing: 1kpcs/Bag

    Inquiry Info. 25407WR

  • 25409W1 2.54 Single1



               Circuit:   2, 3, 4 ~ 40

               Material:   PBT UL 94V0 / Nylon 6T UL94V0

               Contact:  Gold-plated  Brass

               Color: Black

               Packaging: 1Kpcs/Bag

    Inquiry Info. 25409WMS Spec Installation Guide Fluke Test Report Installation Video

  • 25409 2.5 mm Single



               Circuit:   2, 3, 4 ~ 40

               Material:   Nylon 6T  UL 94V0

               Contact:  Gold-plated  Brass

               Color: Black

               Packing: Tube

    Inquiry Info. 25409WMR-SMT Spec Installation Guide Fluke Test Report Installation Video

  • 25407TF-X-X-X 2.54 mm Female Crimp Terminal



            Material: Brass /Phosphor bronze

            Wire Range: #22~ #24 AWG

            Finished: Tin-plated /Gold-flash in contact area

            Packaging:  10kpcs/Reel

    Inquiry Info. 123 456 789
